Model:KMX15RB/B45217A
Part No. :60325647
| 1 | Ring, retaining | 60100508 | 2 |
| 2 | Ring, retaining | 60008801 | 2 |
| 3 | Spring | 60038243 | 2 |
| 4 | Spring | 60038244 | 2 |
| 5 | Cover, spring | 60100505 | 9 |
| 6 | Cover, spring | 60100506 | 2 |
| 7 | Cover, spring | 60100507 | 2 |
| 8 | Cover | 60008789 | 8 |
| 9 | Cover | 60008790 | 1 |
| 10 | Bolt | 60038528 | 2 |
| 11 | Ring, retaining | 60008818 | 9 |
| 12 | Stud | 60008819 | 11 |
| 13 | Plug | 60100466 | 1 |
| 14 | O-ring | 60100514 | 11 |
| 15 | O-ring | 60008821 | 2 |
| 16 | O-ring | 60050051 | 9 |
| 17 | Bolt | 60008721 | 44 |
| 18 | travel spool | 60307380 | 2 |
| 19 | Arm Spool I | 60307381 | 1 |
| 20 | spool boom1 | 60307382 | 1 |
| 21 | Valve core of bucket | 60307383 | 1 |
| 22 | Spool, swing valve | 60100485 | 1 |
| 23 | Arm Spool II | 60307384 | 1 |
| 24 | Spool, valve, boom | 60100480 | 1 |
| 25 | Spool, valve, straight travel | 60100498 | 1 |
| 26 | Spool, service valve | 60100473 | 1 |
| 27 | Valve, hydraulic cutoff | 60100496 | 2 |
| 28 | Valve, swing priority | 60100487 | 1 |
| 29 | Spring | 60008769 | 9 |
| 30 | Spring | 60008770 | 8 |
| 31 | Spring | 60100502 | 1 |
| 32 | Spring | 60100503 | 1 |
| 33 | Spring | 60008771 | 1 |
| 34 | Spring | 60008772 | 1 |
| 35 | Spring | 60039319 | 1 |
| 36 | Seat | 60008825 | 4 |
| 37 | Seat | 60008823 | 22 |
| 1 | Plug | 60008711 | 7 |
| 2 | Plug | 60008712 | 3 |
| 3 | Plug | 60008713 | 6 |
| 4 | Setscrew | 60008728 | 5 |
| 5 | Nameplate | 60100511 | 1 |
| 6 | O-ring | 60008697 | 7 |
| 7 | Rivet | 60008722 | 2 |
| 8 | O-ring | 60008700 | 7 |
| 9 | Bolt | 60008717 | 8 |
| 10 | O-ring | 60100516 | 2 |
| 11 | Flange | 60008781 | 2 |
| 12 | block plate | 60307385 | 1 |
| 13 | valve | 60307386 | 1 |
| 14 | Regenerative Shutoff valve of | 60283390 | 1 |
| 15 | Valve, check | 60008783 | 8 |
| 16 | Spring | 60008817 | 10 |
| 17 | Plug | 60008715 | 11 |
| 18 | O-ring | 60008705 | 17 |
| 19 | Valve, throttle | 60100490 | 6 |
| 20 | Valve, throttle | 60100488 | 2 |
| 21 | Plug | 60100465 | 2 |
| 1 | Plug | 60100467 | 3 |
| 2 | Plug | 60008820 | 3 |
| 3 | Valve, throttle | 60100492 | 3 |
| 4 | Valve, relief, main | 60100500 | 1 |
| 5 | O-ring | 60008703 | 2 |
| 6 | Valve, check | 60100477 | 1 |
| 7 | Plug, oil | 60038656 | 2 |
| 8 | O-ring | 60008696 | 1 |
| 9 | O-ring | 60008708 | 3 |
| 10 | Plug | 60008779 | 2 |
| 11 | Valve GP, control | 60100493 | 2 |
| 12 | Valve, lift | 60038108 | 2 |
| 13 | Valve, check | 60008784 | 2 |
| 14 | Valve, check | 60100475 | 2 |
| 15 | Plug | 60008714 | 1 |
| 16 | Spring | 60100504 | 2 |
| 17 | Spring | 60008765 | 2 |
| 18 | Ball | 60075545 | 1 |
| 19 | Valve, throttle | 60075575 | 1 |
| 20 | Spring | 60075592 | 1 |
| 21 | Valve, check | 60008783 | 8 |
| 22 | Bolt | 60100494 | 1 |
| 1 | O-ring | 60100517 | 3 |
| 2 | O-ring | 60100515 | 21 |
| 3 | O-ring | 60100513 | 14 |
| 4 | Cover | 60100470 | 1 |
| 5 | Bolt | 60100512 | 4 |
| 6 | Bolt | 60100510 | 10 |
